Product Details
Brand Name: FLUKE
Model Number: Fluke 283 FC CAT III 1500V
Document: 45275d4a-3b94-469d-8bf4-b1a...le.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 160$-380$
Delivery Time: 1WEEK
Payment Terms: T/T
|
Mountingoptions:
|
Panel, Wall, Pipe
|
Frequency Range:
|
200 KHz
|
Resolution:
|
Auto Or Manual Ranging, Typically Up To 4-5 Digits
|
Impedance Compatibility:
|
High Or Low
|
Wireless Connectivity:
|
Ir3000 FC Connector
|
Ac Bandwidth:
|
40 Hz - 30 KHz
|
Measurement Technique:
|
2 X 4 Ohms 4-wire
|
Resistance Range:
|
0Ω To 20MΩ
|
Operatingtemperature:
|
-40°C To 125°C
|
|
Mountingoptions:
|
Panel, Wall, Pipe
|
|
Frequency Range:
|
200 KHz
|
|
Resolution:
|
Auto Or Manual Ranging, Typically Up To 4-5 Digits
|
|
Impedance Compatibility:
|
High Or Low
|
|
Wireless Connectivity:
|
Ir3000 FC Connector
|
|
Ac Bandwidth:
|
40 Hz - 30 KHz
|
|
Measurement Technique:
|
2 X 4 Ohms 4-wire
|
|
Resistance Range:
|
0Ω To 20MΩ
|
|
Operatingtemperature:
|
-40°C To 125°C
|
| Function | Range | Resolution | Accuracy |
| AC volts[1] | 6.000 V | 0.001 V | 1.0 % + 3 (45 Hz to 500 Hz) |
| 60.00 V | 0.01 V | ||
| 600.0 V | 0.1 V | 2.0 % + 3 (500 Hz to 1 kHz) |
|
| 1000 V | 1 V | ||
| DC volts | 6.000 V | 0.001 V | 0.09 % + 3 |
| 60.00 V | 0.01 V | ||
| 600.0 V | 0.1 V | ||
| 1500 V | 1 V | 0.15 % + 2 | |
| AC mV[1] | 600.0 mV | 0.1 mV | 1.0% + 3 (45 Hz ~ 500 Hz) 2.0% + 3 (500 Hz ~ 1000 Hz) |
| DC mV | 600.0 mV | 0.1 mV | 0.09 % + 2 |
| Continuity | 600 Ω | 1 Ω | |
| Resistance | 600.0 Ω | 0.1 Ω | 0.5 % + 4 |
| 6.000 kΩ | 0.001 kΩ | ||
| 60.00 kΩ | 0.01 kΩ | ||
| 600.0 kΩ | 0.1 kΩ | ||
| 6.000 MΩ | 0.001 MΩ | ||
| 50.00 MΩ | 0.01 MΩ | 1.5 % + 4 | |
| Capacitance | 1000 nF | 1 nF | 1.2 % + 2 |
| 10.00 μF | 0.01 μF | ||
| 100.0 μF | 0.1 μF | ||
| 9999 μF | 1 μF | 10 % typical | |
| Frequency | 99.99 Hz | 0.01 Hz | 0.1 % + 2 |
| 999.9 Hz | 0.1 Hz | ||
| 9.999 kHz | 0.001 kHz | ||
| 99.99 kHz | 0.01 kHz | ||
| AC VA (45 Hz ~ 500 Hz)[1] | 360.0 VA | 0.1 VA | 2 % + 1.0 VA |
| 3.600 kVA | 0.001 kVA | 2 % + 0.01 kVA | |
| 36.00 kVA | 0.01 kVA | 2 % + 0.1 kVA | |
| 60.00 kVA | 0.01 kVA | 2 % + 0.15 kVA | |
| DC VA[1] | 360.0 VA | 0.1 VA | 2 % + 1.0 VA |
| 3.600 kVA | 0.001 kVA | 2 % + 0.01 kVA | |
| 36.00 kVA | 0.01 kVA | 2 % + 0.1 kVA | |
| 90.00 kVA | 0.01 kVA | 2 % + 0.25 kVA | |
| Min-max avg | For DC functions, accuracy is the specified accuracy of the measurement function ± 12 counts for changes longer than 350 ms in duration. | ||
| For AC functions, accuracy is the specified accuracy of the measurement function ± 40 counts for changes longer than 900 ms in duration. | |||
[1] <1% range, unspecified
| Environmental specifications | |
| Operating temperature | -10 °C to 60 °C |
| Storage temperature | -30 °C to +70 °C |
| Humidity (without condensation) | 0 % to 90 %, 10 °C to 30 °C |
| 0 % to 75 %, 30 °C to 40 °C | |
| 0 % to 45 %, 40 °C to 60 °C | |
| Warranty and Protection | |
| Electromagnetic compatibility | IEC 61326-1, IEC 61326-2-2, Portable, Group 1, Class A |
| Overvoltage category | CAT III 1500 V, CAT IV 1000 V |
| Agency approvals | ETL (AMER and EMEA), CSA (APAC), CE, UK CA |
| Drop test | 2 meter (6.5 ft) drop test |
| Ingress protection | IP52 |
| Warranty | Limited lifetime |
| Mechanical and general specifications | |
| Counts | 6000 |
| Size | 22.5 cm x 10.5 cm x 5.7 cm (8.8 in x 4.1 in x 2.2 in) |
| Weight | 0.7 kg (1.5 lb) |
| Battery life | > 150 hours typical, without backlight (Alkaline, 3 AA) |
| > 100 hours typical when connected to wireless current clamp (Alkaline, 3 AA) | |
