Product Details
Place of Origin: Denmark
Brand Name: PR
Certification: CO
Model Number: PR 6333A
Document: 6333v104_uk.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 280usd
Delivery Time: 5-7 work days
Payment Terms: T/T
Supply Ability: 99pcs 4-6 weeks
|
Relative Humidity:
|
5 To 95%, Non-condensing
|
Output:
|
4-20mADC/1-5VDC
|
Product Type:
|
Redundant Discrete Input Cards
|
Corrent:
|
4-20 MA
|
Storage Temperature:
|
-40 To 85°C (-40 To 185°F)
|
Maximum Allowable:
|
500 Psi (35 Bar)
|
User Memory:
|
48 MB
|
Channel:
|
8 Channels
|
Voltage Rating:
|
DC 115V
|
Primary Power:
|
DC Input, 2-wire
|
Protection Rating:
|
IP65
|
Weight:
|
0.810 Kg (each)
|
Max Span:
|
400/(1000)
|
Generic Code:
|
SICK8
|
|
Relative Humidity:
|
5 To 95%, Non-condensing
|
|
Output:
|
4-20mADC/1-5VDC
|
|
Product Type:
|
Redundant Discrete Input Cards
|
|
Corrent:
|
4-20 MA
|
|
Storage Temperature:
|
-40 To 85°C (-40 To 185°F)
|
|
Maximum Allowable:
|
500 Psi (35 Bar)
|
|
User Memory:
|
48 MB
|
|
Channel:
|
8 Channels
|
|
Voltage Rating:
|
DC 115V
|
|
Primary Power:
|
DC Input, 2-wire
|
|
Protection Rating:
|
IP65
|
|
Weight:
|
0.810 Kg (each)
|
|
Max Span:
|
400/(1000)
|
|
Generic Code:
|
SICK8
|
| Operating temperature | -40°C to +85°C |
| Storage temperature | -40°C to +85°C |
| Calibration temperature | 20...28°C |
| Relative humidity | < 95% RH (non-condensing) |
| Protection degree | IP20 |
| Dimensions (HxWxD) | 109 x 23.5 x 104 mm |
| Weight (1 / 2 channels) | 145 / 185 g |
| DIN rail type | DIN EN 60715/35 mm |
| Wire size | 0.13...2.08 mm² AWG 26...14 stranded wire |
| Screw terminal torque | 0.5 Nm |
| Supply voltage | 8.0...35 VDC |
| Max. required power | ≤ 0.8 W/≤ 1.6 W (1 ch./2 ch.) |
| Internal power dissipation | 0.19...0.8 W |
| Response time (programmable) | 0.33...60 s |
| Voltage drop | 8.0 VDC |
| Warm-up time | 5 min. |
| Programming interface | PR 5909 Loop Link communications interface |
| Signal / noise ratio | Min. 60 dB |
| Accuracy | Better than 0.1% of selected range |
| Signal dynamics, input | 19 bit |
| Signal dynamics, output | 16 bit |
| Effect of supply voltage change | < 0.005% of span / VDC |
| EMC immunity influence | < ±0.5% of span |
| Max. offset | 50% of selected max. value |
| RTD type | Pt100, Ni100, linear R |
| Cable resistance per wire | 10 Ω (max.) |
| Sensor current | > 0.2 mA, < 0.4 mA |
| Effect of sensor cable resistance (3-wire) | < 0.002 Ω / Ω |
| Sensor error detection | Yes |
| Linear resistance range | 0 Ω...10000 Ω |
| Signal range | 4…20 mA |
| Min. signal range | 16 mA |
| Load (@ current output) | ≤ (Vsupply - 8) / 0.023 [Ω] |
| Load stability | ≤ 0.01% of span / 100 Ω |
| Sensor error indication | Programmable 3.5…23 mA |
| NAMUR NE43 Upscale/Downscale | 23 mA / 3.5 mA |
| Updating time | 135 ms |
| Span reference | Presently selected range |
| EMC | 2014/30/EU |
| ATEX | 2014/34/EU |
| RoHS | 2011/65/EU |
| EAC | TR-CU 020/2011 |
| EAC Ex | TR-CU 012/2011 |
| ATEX | DEKRA 20ATEX0106X |
| IECEx | DEK 20.0062X |
| CSA | 1125003 |
| FM | FM17US0013X |
| INMETRO | DEKRA 23.0010X |
| EAC Ex | EAEU KZ 7500361.01.01.08756 |
