Product Details
Place of Origin: USA
Brand Name: Ashcroft
Certification: CO
Model Number: C1033
Document: C1033.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 10-100USD
Delivery Time: 5-7 WORK DAYS
Payment Terms: T/T
Supply Ability: 99PCS 4-6 WEEKS
|
Movement:
|
Brass
|
Overpressure Protection:
|
150% Of Full Scale
|
Case Dimensions:
|
69mm Dia
|
Temperature Range:
|
-40 To 85°C
|
Pointer:
|
Aluminum
|
Working Temperature:
|
-10℃-50℃
|
Ingress Protection:
|
IP67
|
Display:
|
LCD
|
Supply Voltage:
|
10-30 VDC
|
Bourdon Tube Material:
|
Phosphor Bronze
|
Structure:
|
Pump Accessories
|
Communication Protocol:
|
HART
|
Measure Range:
|
-0.1-200Mpa
|
Model:
|
Pressure Gauge
|
Dial Size:
|
4 Inches
|
|
Movement:
|
Brass
|
|
Overpressure Protection:
|
150% Of Full Scale
|
|
Case Dimensions:
|
69mm Dia
|
|
Temperature Range:
|
-40 To 85°C
|
|
Pointer:
|
Aluminum
|
|
Working Temperature:
|
-10℃-50℃
|
|
Ingress Protection:
|
IP67
|
|
Display:
|
LCD
|
|
Supply Voltage:
|
10-30 VDC
|
|
Bourdon Tube Material:
|
Phosphor Bronze
|
|
Structure:
|
Pump Accessories
|
|
Communication Protocol:
|
HART
|
|
Measure Range:
|
-0.1-200Mpa
|
|
Model:
|
Pressure Gauge
|
|
Dial Size:
|
4 Inches
|
High-performance sanitary pressure gauge with fully welded structure that minimizes internal dead corners, making it ideal for pharmaceutical applications and other sanitary processes.
| Pressure Range | Refer to Range and Accuracy Table |
| Accuracy | Refer to Range and Accuracy Table |
| Dial Size | 63mm, 100mm |
| Case Material | 304 Stainless Steel |
| Window Material | Polycarbonate, safety glass (optional) |
| Movement Material | 300 Stainless Steel |
| Pointer | Black aluminum |
| Process Connection Location | Lower, Lower Back |
| Wetted Materials | 316L Stainless Steel, Hastelloy® C276 (Optional) |
| Medium Temperature | Maximum: 138°C (For higher temperatures, cooling tower required or consult factory) |
| Weather Protection | IP65 |
| Case Fill | Food grade glycerin, food grade silicone oil |
| Diaphragm System Oil Fill | Food-grade silicone oil, distilled water |
| Surface Roughness | Diaphragm Ra ≤ 0.38µ; Laser welding seam Ra ≤ 0.76µ; Machined surface Ra ≤ 0.76µ |
| Process Connections | Tri-Clamp®, DIN 32676, BS 4825, ISO 2852 |
| Dial Design | Black figures on white background |
