Product Details
Place of Origin: china
Certification: CO
Model Number: MDM4901FL
Document: mdm4901fl-differential-pres...rs.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 10-100usd
Delivery Time: 5-7 work days
Payment Terms: T/T
Supply Ability: 99pcs 1-2 weeks
|
Responsetime:
|
≤ 1 Ms
|
Pressuretype:
|
Gauge, Absolute, Differential
|
Material:
|
Stainless Steel
|
Productname:
|
Pressure Measurement Instruments
|
Application:
|
Industrial Process Control, HVAC, Hydraulic Systems
|
Protectionrating:
|
IP65
|
Accuracy:
|
±0.25% FS
|
Powersupply:
|
24 V DC
|
Calibration:
|
Factory Calibrated
|
Connectiontype:
|
1/4 Inch NPT
|
Displaytype:
|
Digital LCD
|
Mountingoptions:
|
Panel Mount, Pipe Mount
|
Operatingtemperature:
|
-20°C To 85°C
|
Measurementrange:
|
0 To 1000 Psi
|
Outputsignal:
|
4-20 MA
|
|
Responsetime:
|
≤ 1 Ms
|
|
Pressuretype:
|
Gauge, Absolute, Differential
|
|
Material:
|
Stainless Steel
|
|
Productname:
|
Pressure Measurement Instruments
|
|
Application:
|
Industrial Process Control, HVAC, Hydraulic Systems
|
|
Protectionrating:
|
IP65
|
|
Accuracy:
|
±0.25% FS
|
|
Powersupply:
|
24 V DC
|
|
Calibration:
|
Factory Calibrated
|
|
Connectiontype:
|
1/4 Inch NPT
|
|
Displaytype:
|
Digital LCD
|
|
Mountingoptions:
|
Panel Mount, Pipe Mount
|
|
Operatingtemperature:
|
-20°C To 85°C
|
|
Measurementrange:
|
0 To 1000 Psi
|
|
Outputsignal:
|
4-20 MA
|
| Measurement Range | 0 kPa to 40 kPa... 3.5 MPa |
| Overload Pressure | Positive pressure end ≤ 2 times full range pressure Negative pressure end does not allow overpressure |
| Maximum Static Pressure | ≤ 20 MPa |
| Pressure Type | Differential pressure type |
| Accuracy Details | Available in measurement range and accuracy table |
| Long-term Stability | ± 0.5% FS/year (≤ 200 kPa) ± 0.2% FS/year (> 200 kPa) |
| Operating Temperature | -30 ℃ to 80 ℃ (B1, B11) -20 ℃ to 70 ℃ (B2, cable material: polyethylene) -20 ℃ to 80 ℃ (B2, cable material: polyurethane) |
| Storage Temperature | -40 ℃ to 120 ℃ (B1, B11) -20 ℃ to 85 ℃ (B2) |
| Vibration Resistance | 10g, 30 Hz to 2000 Hz |
| Impact Resistance | 100g, 11 ms |
| Protection Level | IP65 |
| Weight | ≤ 400 g |
