WINTERS PCT CONTRACTOR PRESSURE GAUGE/ PCT-LF LEAD FREE CONTRACTOR GAUGE

Name: WINTERS PCT CONTRACTOR PRESSURE GAUGE/ PCT-LF LEAD FREE CONTRACTOR GAUGE
Brand: Shaanxi Qindiyuan Environmental Protection Equipment Co., Ltd.
SKU: PCT-LF
Price: 400 USD
Availability: InStock

Product Details

Brand Name: WINTERS

Model Number: PCT-LF

Document: PCT.pdf

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 400USD

Delivery Time: 6-8WEEK

Payment Terms: T/T

Supply Ability: 1PC 6-8WEEK

Get Best Price

Chat now

Product Details

Product Description

Highlight:
                                    lead free contractor pressure gauge, PCT contractor pressure gauge, WINTERS pressure measurement instrument


WINTERS PCT CONTRACTOR PRESSURE GAUGE/ PCT-LF LEAD FREE CONTRACTOR GAUGE

WINTERS PCT Contractor Pressure Gauge / PCT-LF Lead Free Contractor Gauge

High-performance industrial dual-scale pressure gauge designed for commercial HVAC, plumbing, and industrial applications with exceptional accuracy and durability.

Product Specifications

Model	WINTERS PCT Series (Contractor Pressure Gauge)
Type	Industrial Dual Scale Pressure Gauge (Dry, Non‑Fillable)
Dial Size	4.5" (115 mm)
Accuracy (25°C)	±1.0% Full Scale (FS), ASME B40.100 Grade 1A
Case Material	304 Stainless Steel (Silver Finish)
Bezel	304 Stainless Steel, Crimped (Non‑Removable)
Wetted Parts	Brass Alloy (Standard)
Process Connection	1/4" NPT Male (Bottom Mount, Standard)
Enclosure Rating	NEMA 4 / IP65
Compliance	ASME B40.100, CRN Registered, RoHS Compliant

Pressure Ranges

Vacuum: 30"Hg Vacuum / -1 bar
Compound: -30 to 300 psi / -1 to 20 bar
Gauge: 0‑15 psi to 0‑350 bar (0‑1 bar to 0‑350 bar)

Operating Conditions

Over‑Pressure Limit: 130% of Full Scale
Working Pressure: Max 75% of Full Scale
Ambient Temperature: -40°F to 200°F (-40°C to 93°C)
Process Temperature: -40°F to 200°F (-40°C to 93°C)
Storage Temperature: -40°F to 200°F (-40°C to 93°C)

Key Features

External recalibration screw for easy adjustment
Economical stainless steel case construction
Dual scale display (psi/kPa) for versatile applications
Brass movement with overload stops for protection
Polycarbonate lens for durability and clarity
White aluminum dial with black markings
Black anodized aluminum pointer

Applications: Commercial HVAC Plumbing Water Systems Steam Applications Air Service

Warranty: 5 Years Comprehensive Coverage
