AC DC Universal Signal Transmitter PR 4179 Outputs Passive / Active Current Signals

Name: AC DC Universal Signal Transmitter PR 4179 Outputs Passive / Active Current Signals
Brand: Shaanxi Qindiyuan Environmental Protection Equipment Co., Ltd.
SKU: PR 4179
Price: 250.00 USD
Availability: InStock

Product Details

Place of Origin: Denmark

Brand Name: PR

Certification: CO

Model Number: PR 4179

Document: 4179v102_uk.pdf

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 150usd -350usd

Delivery Time: 5-7 work days

Payment Terms: T/T

Supply Ability: 99pcs 4-6 weeks

Get Best Price

Chat now

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                            Signal Transmitter PR 4179, AC / DC Signal Transmitter


Mountingoptions:	Panel Mount, Wall Mount	Calibration:	Factory Calibrated
Material:	Stainless Steel	Responsetime:	Less Than 1 Second
Application:	Industrial Process Control, HVAC, Hydraulic Systems	Displaytype:	Digital LCD
Powersupply:	24 V DC	Protectionrating:	IP65
Measurementrange:	0 To 1000 Psi	Productname:	Pressure Measurement Instruments
Connectiontype:	1/4 Inch NPT	Pressuretype:	Gauge, Absolute, Differential
Outputsignal:	4-20 MA, 0-10 V	Accuracy:	±0.25% Of Full Scale
Operatingtemperature:	-20°C To 85°C

Mountingoptions:	Panel Mount, Wall Mount
Calibration:	Factory Calibrated
Material:	Stainless Steel
Responsetime:	Less Than 1 Second
Application:	Industrial Process Control, HVAC, Hydraulic Systems
Displaytype:	Digital LCD
Powersupply:	24 V DC
Protectionrating:	IP65
Measurementrange:	0 To 1000 Psi
Productname:	Pressure Measurement Instruments
Connectiontype:	1/4 Inch NPT
Pressuretype:	Gauge, Absolute, Differential
Outputsignal:	4-20 MA, 0-10 V
Accuracy:	±0.25% Of Full Scale
Operatingtemperature:	-20°C To 85°C

AC DC Universal Signal Transmitter PR 4179 Outputs Passive / Active Current Signals

Environmental Conditions

Operating temperature	-20°C to +60°C
Storage temperature	-20°C to +85°C
Calibration temperature	20...28°C
Relative humidity	< 95% RH (non-cond.)
Protection degree	IP20
Installation in	Pollution degree 2 & meas. / overvoltage cat. II

Mechanical specifications

Dimensions (HxWxD)	109 x 23.5 x 104 mm
Dimensions (HxWxD) w/ PR 4500	109 x 23.5 x 131 mm
Weight approx.	155 g
Weight incl. 4501 / 451x (approx.)	170 g / 185 g
DIN rail type	DIN EN 60715/35 mm
Wire size	0.13...2.08 mm² AWG 26...14 stranded wire
Screw terminal torque	0.5 Nm
Vibration	IEC 60068-2-6
2...13.2 Hz	±1 mm
13.2...100 Hz	±0.7 g

Common specifications

Supply
Supply voltage, universal	21.6...253 VAC, 50...60 Hz or 19.2...300 VDC
Max. required power	1.6 W
Max. power dissipation - current measurement	2.7 W
Max. power dissipation - voltage measurement	1.6 W
Isolation voltage
Test voltage	2.3 kVAC
Working voltage	250 VAC (reinforced) / 500 VAC (basic)
Response time
Response time (0...90%, 100...10%)	< 0.75 s
Programming	PR 4500 communication interfaces
Signal dynamics, input	20 bit
Signal dynamics, output	18 bit
Signal / noise ratio	> 60 dB
Output referred common mode rejection ratio	0.02 ppm / VHz
Accuracy	Better than 0.3% of selected range*
EMC immunity influence	< ±0.5% of span*
Extended EMC immunity: NAMUR NE21, A criterion, burst	< ±1% of span*
of span	= of selected standard range

Input specifications

Current input
Signal range	0...5 AAC / 40...400 Hz
Maximum input limit	6.00 AAC @ 40°C
Programmable measurement ranges	0...0.5; 0…1; 0…2.5 & 0...5 AAC
Custom configurable signal range	0...5 AAC /40...400 Hz
Min. measurement range (span)	0.5 AAC
Input resistance	< 0.042 Ω (incl. terminals)
Voltage input
Signal range	0...300 VAC / 40...400 Hz
Programmable measurement ranges	0...0.5, 0...1, 0...2.83, 0…5, 0…120, 0…230 & 0…300 VAC
Custom configurable signal range	0...300 VAC / 40...400 Hz
Min. measurement range (span)	0.5 VAC
Input resistance	Nom. 3 MΩ \|\| 100 pF

Output specifications

Active unipolar and bipolar mA output
Programmable ranges	0...20, 4...20 and S4...20 mA ±10 and ±20 mA Direct or Inverted Action
Load (@ current output)	≤ 800 Ω
V-curve function, active signals, 100-0-100%	20-0-20 mA
Passive 2-wire mA output
Programmable ranges	0...20 and 4...20 mA Direct or Inverted action
V-curve function, 100-0-100%	20-0-20 mA
External loop supply	3.5...30 V
Current output
Signal range	0...23 mA (unipolar) -23...+23 mA (bipolar)
Current limit	≤ 28 mA (unipolar) ± 28 mA (bipolar)
Load stability	≤ 0.001% of span / 100 Ω
Response time, programmable	0.0...60.0 s
Voltage output
Programmable signal ranges	0/0.2...1; 0/1...5 ; 0/2...10; 1...0.2/0; 5...1/0; 10...2/0 V ±1, ±5 and ±10 V Direct or Inverted action
V-curve function, 100-0-100%	1-0-1, 5-0-5 and 10-0-10 V
Load (@ voltage output)	≥ 500 kΩ
Response time, programmable	0.0...60.0 s

Observed authority requirements

EMC	2014/30/EU & UK SI 2016/1091
LVD	2014/35/EU & UK SI 2016/1101
RoHS	2011/65/EU & UK SI 2012/3032
EAC	TR-CU 020/2011

Approvals

c UL us, UL 508	E248256
SIL	Hardware assessed for use in SIL applications

NB

* / **

For custom configurable signal ranges, general accuracy and EMC specifications are 0.3% of full scale
