Product Details
Brand Name: WINTERS
Model Number: PFQ-40
Document: PFQ-EN.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 30USD
Delivery Time: 1-2WEEK
Payment Terms: T/T
Supply Ability: 1PC 1-2WEEK
|
Outputsignal:
|
4-20 MA
|
Pressuretype:
|
Gauge, Absolute, Differential
|
Accuracy:
|
±0.25% FS
|
Calibration:
|
Factory Calibrated
|
Responsetime:
|
≤ 1 Second
|
Application:
|
Industrial, HVAC, Hydraulic Systems
|
Material:
|
Stainless Steel
|
Powersupply:
|
24 V DC
|
Connectiontype:
|
1/4 Inch NPT
|
Displaytype:
|
Digital LCD
|
Operatingtemperature:
|
-20°C To 85°C
|
Mountingoptions:
|
Panel, Wall, Pipe
|
Protectionrating:
|
IP65
|
Measurementrange:
|
0 To 1000 Psi
|
Productname:
|
Pressure Measurement Instruments
|
|
Outputsignal:
|
4-20 MA
|
|
Pressuretype:
|
Gauge, Absolute, Differential
|
|
Accuracy:
|
±0.25% FS
|
|
Calibration:
|
Factory Calibrated
|
|
Responsetime:
|
≤ 1 Second
|
|
Application:
|
Industrial, HVAC, Hydraulic Systems
|
|
Material:
|
Stainless Steel
|
|
Powersupply:
|
24 V DC
|
|
Connectiontype:
|
1/4 Inch NPT
|
|
Displaytype:
|
Digital LCD
|
|
Operatingtemperature:
|
-20°C To 85°C
|
|
Mountingoptions:
|
Panel, Wall, Pipe
|
|
Protectionrating:
|
IP65
|
|
Measurementrange:
|
0 To 1000 Psi
|
|
Productname:
|
Pressure Measurement Instruments
|
| Parameter | Specification |
|---|---|
| Model | PFQ-40 |
| Brand | Winters Instruments |
| Dial Size | 1.5" (40mm) |
| Case Material | AISI 304 Stainless Steel |
| Wetted Parts | Brass (316 Stainless Steel Optional) |
| Window Material | Polycarbonate (PC) |
| Bezel | AISI 304 Stainless Steel Crimped Bezel (Optional U-Clamp for Panel Mounting) |
| Movement | Standard Mechanical Movement (Optional Liquid-Filled for Vibration Resistance) |
| Accuracy Class | ±2.5% Full Scale (FS) |
| Scale | Single (psi) or Dual Scale (psi/kPa, psi/bar, etc.) |
| Pressure Range | Multiple Ranges Available (e.g., Vacuum to 15 psi, 30 psi, 60 psi, 100 psi, etc.) |
| Connection | 1/8" NPT Male (Standard), Axial Mounting (Bottom Connection) |
| Mounting Type | Axial (Bottom Connection) |
| Ambient Temperature | -20°C to 70°C |
| Medium Temperature | -40°C to 150°C (Dry); -40°C to 100°C (Liquid-Filled) |
| Storage Temperature | -20°C to 70°C |
| Over-Pressure Limit | Steady Pressure: 75% FS; Fluctuating Pressure: 65% FS; Short-term Pressure: 100% FS (Brass Tube) |
| IP Rating | IP65 (EN 60529) |
| Certification | CRN Registered; Optional NSF-61-372 (Lead-Free PFQ-LF) |
