Shaanxi Qindiyuan Environmental Protection Equipment Co., Ltd.
leonleesale@aliyun.com
86--15389206502
Product Details
Place of Origin: CHINA
Brand Name: Hanwei
Model Number: GTQ-WD2200
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 350$
Delivery Time: 1WEEK
Payment Terms: T/T
|
Sensor Type:
|
Catalytic Combustion
|
Sampling Method:
|
Natural Diffusion
|
Operating Voltage:
|
AC220V±20%
|
Power Consumption:
|
≤3W
|
Response Time:
|
T90＜20s
|
Protection Rating:
|
IP66/67
|
Operating Temperature:
|
-40~70℃
|
Dimensions:
|
168 X 193 X 82 (mm)
|
|
Sensor Type:
|
Catalytic Combustion
|
|
Sampling Method:
|
Natural Diffusion
|
|
Operating Voltage:
|
AC220V±20%
|
|
Power Consumption:
|
≤3W
|
|
Response Time:
|
T90＜20s
|
|
Protection Rating:
|
IP66/67
|
|
Operating Temperature:
|
-40~70℃
|
|
Dimensions:
|
168 X 193 X 82 (mm)
|
Professional-grade point-type gas detector designed for reliable monitoring of flammable gases in industrial environments.
| Sensor Type | Catalytic Combustion |
|---|---|
| Sampling Method | Natural Diffusion |
| Application Environment | Outdoor Type |
| Operating Voltage | AC220V±20% |
| Power Consumption | ≤3W |
| Alarm Deviation | ±3%LEL |
| Response Time | T90＜20s |
| Low Alarm Setting | 20%LEL |
| High Alarm Setting | 50%LEL |
| Operating Mode | Continuous Monitoring |
| Control Method | Infrared Remote Control |
| Operating Environment | Temperature: -40~70℃, Humidity: ≤95%RH (non-condensing) |
| Protection Rating | IP66/67 |
| Explosion Protection Type | Flameproof |
| Explosion Protection Rating | Ex db ll CT6 Gb/Ex tb lll C T80°C Db |
| Housing Material | Aluminum Alloy |
| Dimensions | 168 x 193 x 82 (mm) |
| Weight | ＜1.2kg |
