Product Details
Place of Origin: CHINA
Brand Name: Hanwei
Model Number: GTY-CXL
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 250$
Delivery Time: 1WEEK
Payment Terms: T/T
|
Detection Principle:
|
Catalytic Combustion Type, Electrochemical Type
|
Detection Method:
|
Natural Diffusion Type
|
Response Time:
|
T90 ≤ 15s
|
Protection Grade:
|
IP66/IP67
|
Operating Temperature:
|
-40℃ To +70℃
|
Operating Humidity:
|
0 To 95%RH (no Condensation)
|
Power Supply:
|
DC24V ± 6V
|
Power Consumption:
|
≤ 3.6W
|
|
Detection Principle:
|
Catalytic Combustion Type, Electrochemical Type
|
|
Detection Method:
|
Natural Diffusion Type
|
|
Response Time:
|
T90 ≤ 15s
|
|
Protection Grade:
|
IP66/IP67
|
|
Operating Temperature:
|
-40℃ To +70℃
|
|
Operating Humidity:
|
0 To 95%RH (no Condensation)
|
|
Power Supply:
|
DC24V ± 6V
|
|
Power Consumption:
|
≤ 3.6W
|
| Specification | Details |
|---|---|
| Detection Principle | Catalytic combustion type, electrochemical type |
| Detection Method | Natural diffusion type |
| Response Time | t90 ≤ 15s (depending on gas type) |
| Protection Grade | IP66/IP67 |
| Operating Temperature | -40℃ to +70℃ |
| Operating Humidity | 0 to 95%RH (no condensation) |
| Environmental Pressure | 86KPa to 106KPa |
| Parameter | Specification |
|---|---|
| Power Supply Voltage | DC24V ± 6V |
| Power Consumption | ≤ 3.6W |
| Characteristic | Details |
|---|---|
| Shell Material | Stainless Steel |
| Product Weight | Approximately 5.5kg |
| Overall Dimensions | 130mm x 209mm x 116mm |
