Product Details
Place of Origin: china
Certification: CO
Model Number: MPM4760
Document: MDM4760-datasheet-156203618...2).pdf
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 10-100usd
Delivery Time: 5-7 work days
Payment Terms: T/T
Supply Ability: 99pcs 1-2 weeks
|
Responsetime:
|
≤ 1 Ms
|
Pressuretype:
|
Gauge, Absolute, Differential
|
Material:
|
Stainless Steel
|
Productname:
|
Pressure Measurement Instruments
|
Application:
|
Industrial Process Control, HVAC, Hydraulic Systems
|
Protectionrating:
|
IP65
|
Accuracy:
|
±0.25% FS
|
Powersupply:
|
24 V DC
|
Calibration:
|
Factory Calibrated
|
Connectiontype:
|
1/4 Inch NPT
|
Displaytype:
|
Digital LCD
|
Mountingoptions:
|
Panel Mount, Pipe Mount
|
Operatingtemperature:
|
-20°C To 85°C
|
Measurementrange:
|
0 To 1000 Psi
|
Outputsignal:
|
4-20 MA
|
|
Responsetime:
|
≤ 1 Ms
|
|
Pressuretype:
|
Gauge, Absolute, Differential
|
|
Material:
|
Stainless Steel
|
|
Productname:
|
Pressure Measurement Instruments
|
|
Application:
|
Industrial Process Control, HVAC, Hydraulic Systems
|
|
Protectionrating:
|
IP65
|
|
Accuracy:
|
±0.25% FS
|
|
Powersupply:
|
24 V DC
|
|
Calibration:
|
Factory Calibrated
|
|
Connectiontype:
|
1/4 Inch NPT
|
|
Displaytype:
|
Digital LCD
|
|
Mountingoptions:
|
Panel Mount, Pipe Mount
|
|
Operatingtemperature:
|
-20°C To 85°C
|
|
Measurementrange:
|
0 To 1000 Psi
|
|
Outputsignal:
|
4-20 MA
|
| Measurement Range | -100kPa…0kPa ~ 10kPa…100MPa |
|---|---|
| Overpressure Rating | 1.5 times FS or 110MPa (minimum value applies) |
| Measurement Range | 0kPa ~ 35kPa…3.5MPa |
|---|---|
| +Overpressure | 2 times FS |
| -Overpressure | FS |
| Maximum Static Pressure | ≤20MPa |
| Total Accuracy | ±0.25%FS |
|---|---|
| Stability | ±0.2%FS/YEAR |
| Compensated Temperature | -10℃ ~ 70℃ |
| Working Temperature | -30℃ ~ 80℃ |
| Storage Temperature | -40℃ ~ 85℃ |
| Power Supply | 8V ~ 28V DC or Battery Supply |
| Output Signal Standard | Analog 4mA ~ 20mA DC, 2-wire; Digital RS485 Interface |
| RS485 Interface | ASCII Agreement or MODBUS RTU, BUS with 99 transmitters |
| Load Resistance (Ω) | (U-8V)/0.02A (U is power voltage - standard) |
| Display Range | -19999 ~ 19999 LCD Display |
| Insulation | 50V, 100M |
| Shock Resistance | 20g, 20Hz ~ 5000Hz |
| Impact Resistance | 20g, 11ms |
| Protection Rating | IP65 |
| Weight | ~420g |
| Housing | Stainless Steel |
|---|---|
| Diaphragm | Stainless Steel 316L |
| O-Ring | Viton |
