Product Details
Place of Origin: china
Certification: CO
Model Number: MPM3803
Document: MPM380-Pressure-Transducer.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 10-100usd
Delivery Time: 5-7 work days
Payment Terms: T/T
Supply Ability: 99pcs 1-2 weeks
|
Responsetime:
|
≤ 1 Ms
|
Pressuretype:
|
Gauge, Absolute, Differential
|
Material:
|
Stainless Steel
|
Productname:
|
Pressure Measurement Instruments
|
Application:
|
Industrial Process Control, HVAC, Hydraulic Systems
|
Protectionrating:
|
IP65
|
Accuracy:
|
±0.25% FS
|
Powersupply:
|
24 V DC
|
Calibration:
|
Factory Calibrated
|
Connectiontype:
|
1/4 Inch NPT
|
Displaytype:
|
Digital LCD
|
Mountingoptions:
|
Panel Mount, Pipe Mount
|
Operatingtemperature:
|
-20°C To 85°C
|
Measurementrange:
|
0 To 1000 Psi
|
Outputsignal:
|
4-20 MA
|
|
Responsetime:
|
≤ 1 Ms
|
|
Pressuretype:
|
Gauge, Absolute, Differential
|
|
Material:
|
Stainless Steel
|
|
Productname:
|
Pressure Measurement Instruments
|
|
Application:
|
Industrial Process Control, HVAC, Hydraulic Systems
|
|
Protectionrating:
|
IP65
|
|
Accuracy:
|
±0.25% FS
|
|
Powersupply:
|
24 V DC
|
|
Calibration:
|
Factory Calibrated
|
|
Connectiontype:
|
1/4 Inch NPT
|
|
Displaytype:
|
Digital LCD
|
|
Mountingoptions:
|
Panel Mount, Pipe Mount
|
|
Operatingtemperature:
|
-20°C To 85°C
|
|
Measurementrange:
|
0 To 1000 Psi
|
|
Outputsignal:
|
4-20 MA
|
| Parameter | Specification |
|---|---|
| Pressure Range | -100kPa…0kPa ~ 20kPa…100MPa |
| Overpressure | 2 times FS or 110MPa (minimum value is valid) |
| Power Supply | 1.5mA DC |
| Signal Output | ≥70mV DC (0kPa~20kPa, ≥50mV DC) |
| Accuracy | ±0.1%FS (min) ±0.25%FS (typ) ±0.5%FS (max) |
| Long-term Stability | ±0.3%FS/year |
| Compensation Temperature | 0℃ ~ 50℃ |
| Operation Temperature | -30℃ ~ 80℃ (-10℃ ~ 70℃ with Cable) |
| Storage Temperature | -40℃ ~ 120℃ (-20℃ ~ 85℃ with Cable) |
| Zero Temperature Coefficient | ±0.02%FS/℃ (typ.) ±0.04%FS/℃ (max.) |
| FS Temperature Coefficient | ±0.02%FS/℃ (typ.) ±0.04%FS/℃ (max.) |
| Response Time (10%-90%) | ≤1ms |
| Insulation Resistance | 100MΩ, 100V DC |
| Protection Rating | IP65 (cable connection) |
