Product Details
Place of Origin: china
Certification: CO
Model Number: MPM4530
Document: MPM4530-Pressure-Transmitte...er.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 10-100usd
Delivery Time: 5-7 work days
Payment Terms: T/T
Supply Ability: 99pcs 1-2 weeks
|
Responsetime:
|
≤ 1 Ms
|
Pressuretype:
|
Gauge, Absolute, Differential
|
Material:
|
Stainless Steel
|
Productname:
|
Pressure Measurement Instruments
|
Application:
|
Industrial Process Control, HVAC, Hydraulic Systems
|
Protectionrating:
|
IP65
|
Accuracy:
|
±0.25% FS
|
Powersupply:
|
24 V DC
|
Calibration:
|
Factory Calibrated
|
Connectiontype:
|
1/4 Inch NPT
|
Displaytype:
|
Digital LCD
|
Mountingoptions:
|
Panel Mount, Pipe Mount
|
Operatingtemperature:
|
-20°C To 85°C
|
Measurementrange:
|
0 To 1000 Psi
|
Outputsignal:
|
4-20 MA
|
|
Responsetime:
|
≤ 1 Ms
|
|
Pressuretype:
|
Gauge, Absolute, Differential
|
|
Material:
|
Stainless Steel
|
|
Productname:
|
Pressure Measurement Instruments
|
|
Application:
|
Industrial Process Control, HVAC, Hydraulic Systems
|
|
Protectionrating:
|
IP65
|
|
Accuracy:
|
±0.25% FS
|
|
Powersupply:
|
24 V DC
|
|
Calibration:
|
Factory Calibrated
|
|
Connectiontype:
|
1/4 Inch NPT
|
|
Displaytype:
|
Digital LCD
|
|
Mountingoptions:
|
Panel Mount, Pipe Mount
|
|
Operatingtemperature:
|
-20°C To 85°C
|
|
Measurementrange:
|
0 To 1000 Psi
|
|
Outputsignal:
|
4-20 MA
|
The MPM4530 high-temperature pressure transmitter utilizes a specialized high-temperature resistant pressure sensor as the primary signal measuring component. This advanced sensor features a dual-membrane construction designed for optimal performance in demanding industrial environments.
| Pressure Range | -0.1MPa…0MPa~0.01MPa…160MPa (Gauge) 0MPa~0.025MPa…60MPa (Absolute) |
| Over Pressure | 200% FS or 150MPa (minimum value applies) |
| Compatible Media | Liquid or gas compatible with stainless steel |
| Power Supply | 10~30VDC (24VDC recommended) |
| Output Signal | 4~20mADC 2-wire |
| Load | RL ≤ ((U-10)/0.02)(Ω) |
| Accuracy | ±0.25%FS, ±0.5%FS (including non-linearity, repeatability, and hysteresis) |
| Thermal Error | ≤±0.025%FS/℃ (@25℃) |
| Long-term Stability | ≤±0.5%FS/year |
| Endurance | 10⁶ pressure cycles |
| Environment Temperature | -40℃ ~ +80℃ |
| Media Temperature | -40℃ ~ +150℃ |
| Relative Humidity | 0~90%RH |
| Protection | IP65 |
| Response | >1kHz |
| Insulation | 100MΩ, 50VDC |
| Materials | Pressure port and housing: Stainless steel 1Cr18Ni9Ti |
| Wiring Connection | Hirschmann plug |
