Product Details
Place of Origin: china
Certification: CO
Model Number: MPM489S
Document: info-cz mpm489-0-50mv1j24b2...3a.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 10-100usd
Delivery Time: 5-7 work days
Payment Terms: T/T
Supply Ability: 99pcs 1-2 weeks
|
Responsetime:
|
≤ 1 Ms
|
Pressuretype:
|
Gauge, Absolute, Differential
|
Material:
|
Stainless Steel
|
Productname:
|
Pressure Measurement Instruments
|
Application:
|
Industrial Process Control, HVAC, Hydraulic Systems
|
Protectionrating:
|
IP65
|
Accuracy:
|
±0.25% FS
|
Powersupply:
|
24 V DC
|
Calibration:
|
Factory Calibrated
|
Connectiontype:
|
1/4 Inch NPT
|
Displaytype:
|
Digital LCD
|
Mountingoptions:
|
Panel Mount, Pipe Mount
|
Operatingtemperature:
|
-20°C To 85°C
|
Measurementrange:
|
0 To 1000 Psi
|
Outputsignal:
|
4-20 MA
|
|
Responsetime:
|
≤ 1 Ms
|
|
Pressuretype:
|
Gauge, Absolute, Differential
|
|
Material:
|
Stainless Steel
|
|
Productname:
|
Pressure Measurement Instruments
|
|
Application:
|
Industrial Process Control, HVAC, Hydraulic Systems
|
|
Protectionrating:
|
IP65
|
|
Accuracy:
|
±0.25% FS
|
|
Powersupply:
|
24 V DC
|
|
Calibration:
|
Factory Calibrated
|
|
Connectiontype:
|
1/4 Inch NPT
|
|
Displaytype:
|
Digital LCD
|
|
Mountingoptions:
|
Panel Mount, Pipe Mount
|
|
Operatingtemperature:
|
-20°C To 85°C
|
|
Measurementrange:
|
0 To 1000 Psi
|
|
Outputsignal:
|
4-20 MA
|
| Parameter | Specification |
|---|---|
| Pressure Range | -100kPa…0kPa~10kPa…100MPa |
| Overpressure | ≤1.5 times FS or 110MPa (min. value is valid) |
| Pressure Type | Gauge / Absolute / Sealed Gauge |
| Process Connection | M20*1.5 male waterline seal (or custom available) |
| Accuracy | ≤±0.5%FS |
| Long Term Stability | ≤ ±0.3%FS/year |
| Zero Thermal Drift | ≤±0.05%FS/℃(≤100kPa); ≤±0.03%FS/℃(>100kPa) |
| Span Thermal Drift | ≤±0.05%FS/℃(≤100kPa); ≤±0.03%FS/℃(<100kPa) |
| Compensation Temperature | 0℃~50℃ |
| Application Temperature | -30℃~80℃ (-10℃~60℃ Exia, -20℃~60℃ Exd, -10℃~70℃ Cable) |
| Storage Temperature | -40℃~120℃ (-20℃~85℃ Cable) |
| Power Supply | 11V~28VDC, 3.3V/5V DC |
| Output Signal | 4mA~20mA DC (2-wire), 0/1~5/10V DC (3-wire), 0.5V~2.5V/4.5V DC (3-wire) |
| Load | ≤(U-11)/0.02Ω (2-wire), ≥10k (3-wire) |
| Housing Protection | IP65 |
| Electric Connection | DIN43650 plug or cable (1.5m) |
