Product Details
Place of Origin: CHINA
Brand Name: HONEYWELL
Certification: CO
Model Number: STR73D-2ICSIF0-KJGJBCDSG-C-CHC-11C-B-21A6-F1
Document: STG70S_Gauge Pressure Trans...rs.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 700$-1200$
Delivery Time: 10-12WEEKS
Payment Terms: T/T
|
Thread:
|
1/4npt
|
Zero Offset:
|
≤±0.2mV/V
|
Ingress Protection:
|
IP67
|
Air Source Pressure:
|
0.14~1MPa
|
Warranty:
|
1 Year
|
Output:
|
4-20mA/0-5V/0-10V/RS485
|
Protection:
|
IP65
|
Measuring Range:
|
0-1kPa-10MPa
|
|
Thread:
|
1/4npt
|
|
Zero Offset:
|
≤±0.2mV/V
|
|
Ingress Protection:
|
IP67
|
|
Air Source Pressure:
|
0.14~1MPa
|
|
Warranty:
|
1 Year
|
|
Output:
|
4-20mA/0-5V/0-10V/RS485
|
|
Protection:
|
IP65
|
|
Measuring Range:
|
0-1kPa-10MPa
|
Model: STR73D-2ICSIF0-KJGJBCDSG-C-CHC-11C-B-21A6-F1
Estimated Lead Time: 10-12 weeks
Shipping Weight: 10 Kg
Manufacturer: Honeywell
Product Type: STR73D SmartLine Pressure Transmitter with Remote Diaphragm Seals
| Number of Seals | 1 Remote Seal (High Side) |
| Primary Fill Fluid | Silicone Oil 200 |
| Secondary Fill Fluid | Silicone Oil 200 |
| Connection Type | Capillary Length: 10 feet (3.0m), SS Armor |
| Seal Configuration | Flush Flanged Seal | Diaphragm Diameter: 3.5" | Flange Size: 3" | Flange Pressure Rating: ANSI Class 300 |
| Wetted Materials | Diaphragm: Monel 400® | Upper Insert: Monel 400® |
| Non-Wetted Materials | 316L SS |
| Electronic Housing | 316 Stainless Steel (Grade CF8M), 1/2 NPT Connection |
| Output Protocol | 4-20mA dc Analog Output with HART Protocol |
| Approvals | FM Explosion proof, Intrinsically Safe, Non-incendive, & Dustproof |
