Product Details
Place of Origin: china
Certification: CO
Model Number: M20
Document: M20-Pressure-Transmitter-su...ry.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 10-100usd
Delivery Time: 5-7 work days
Payment Terms: T/T
Supply Ability: 99pcs 1-2 weeks
|
Responsetime:
|
≤ 1 Ms
|
Pressuretype:
|
Gauge, Absolute, Differential
|
Material:
|
Stainless Steel
|
Productname:
|
Pressure Measurement Instruments
|
Application:
|
Industrial Process Control, HVAC, Hydraulic Systems
|
Protectionrating:
|
IP65
|
Accuracy:
|
±0.25% FS
|
Powersupply:
|
24 V DC
|
Calibration:
|
Factory Calibrated
|
Connectiontype:
|
1/4 Inch NPT
|
Displaytype:
|
Digital LCD
|
Mountingoptions:
|
Panel Mount, Pipe Mount
|
Operatingtemperature:
|
-20°C To 85°C
|
Measurementrange:
|
0 To 1000 Psi
|
Outputsignal:
|
4-20 MA
|
|
Responsetime:
|
≤ 1 Ms
|
|
Pressuretype:
|
Gauge, Absolute, Differential
|
|
Material:
|
Stainless Steel
|
|
Productname:
|
Pressure Measurement Instruments
|
|
Application:
|
Industrial Process Control, HVAC, Hydraulic Systems
|
|
Protectionrating:
|
IP65
|
|
Accuracy:
|
±0.25% FS
|
|
Powersupply:
|
24 V DC
|
|
Calibration:
|
Factory Calibrated
|
|
Connectiontype:
|
1/4 Inch NPT
|
|
Displaytype:
|
Digital LCD
|
|
Mountingoptions:
|
Panel Mount, Pipe Mount
|
|
Operatingtemperature:
|
-20°C To 85°C
|
|
Measurementrange:
|
0 To 1000 Psi
|
|
Outputsignal:
|
4-20 MA
|
| Connection Type | Specification |
|---|---|
| 4-pin Connector | DIN 175301-803A |
| Circular Aviation Connector | M12*1 (4 pin) IEC 61076-2-101 |
| Cable | Φ5.0mm 5* 0.12mm² PUR |
| Connection Type | Standard |
|---|---|
| M20*1.5 | ISO 9974-2/EN 837 |
| G1/4A | ISO 1179-2 |
| NPT1/4 | ANSI/ASME B1.20.1 |
| R1/4 | ISO 7 |
| Signal Type | Range |
|---|---|
| Current Output | 4mA ~ 20mA DC |
| Voltage Output | 0V ~ 5V DC |
| Voltage Output | 1V ~ 5V DC |
| Voltage Output | 0V ~ 10V DC |
| Voltage Output | 0.5V ~ 4.5V DC |
